Lipoly battery charge circuit for portable use.Beautiful silkscreen with a boop-able nose that is a capacitive touch pad.Two 240x240 IPS TFT displays each on their own SPI bus.8 MB QSPI flash for storing graphics and sound effects.ATSAMD51G19 Cortex M4 microcontroller running at 120MHz with 512KB Flash, 192KB RAM.This is by far the cutest, creepiest and most incredible development board we've made so far! Gaze upon these features: Speaking of that nose, the silkscreen is by the skillful Miss Monster, check out those fangs!
There's also plenty of sensors built in - light sensor, 3 tactile buttons, and a capacitive touch pad on the nose. For the PDM mic port, you can use this cable to wire to a PDM mic. The 4-pin JST connector connects to the I2C port and you can fit Grove connectors in it for additional hardware support. The 3-pin JSTs connect to analog/timer pins on the SAMD51, so you can use them for sensors or GPIO devices. On each side are JST-PH plugs for connecting external devices. For small portable effects, the built-in amp can drive 8 ohm speakers up to 1 Watt. Use it when you want an externally sound amplifier box for big effects. We wanted to make audio-effects easier so in addition to a class D audio amp, there's also a stereo headphone jack that is connected to the two DACs on the chip. This unique design has the eyes at the same pupil-distance as a human (~63mm) but is designed so that the nose section can be broken apart with pliers/cutters and then wired together with a 9-pin JST SH cable up to 100mm long so the eyes can be re-positioned or freely attached.
#Electronic eye timer full#
You'll get the same quality display as our Raspberry Pi Eyes kit but without needing to tote around a full Linux computer Peep dis! Have you always wanted to have another pair of eyes on the back of your head? Or outfit your costume with big beautiful orbs? The MONSTER M4SK is like the Hallowing but twice as good, with two gorgeous 240x240 pixel IPS TFT displays, driven by a 120MHZ Cortex M4 processor that can pump out those pixels super fast.
